You just invested in a brand new imaging system for your dental practice. The hardware is installed, the sensor feels right in your hand, and the image quality is incredible.
But there is one problem.
It does not talk to your practice management software yet.
This is one of the most common frustrations we hear from dental offices. The good news is that integration is almost always achievable, and it does not have to be painful.
Below is a step-by-step guide to getting your new imaging equipment and your practice management software working together seamlessly.
Step 1: Confirm Compatibility Before You Panic
Before diving into settings and cables, take a breath and verify that your imaging system and practice management software are actually compatible.
Most modern imaging solutions, including the systems we sell at Global Imaging USA, are designed to work with the major PMS platforms.
Common compatible PMS platforms include:
• Dentrix and Dentrix Ascend
• Eaglesoft
• Open Dental
• Curve Dental
• And many others
Check the documentation that came with your imaging system for a list of supported integrations. If you are unsure, give us a call. We can confirm compatibility in minutes.
Step 2: Install the Imaging Software and Drivers
Your imaging hardware needs its own companion software to capture and process images. This is separate from your practice management software.
Typical setup steps include:
• Install the imaging capture software and drivers on each workstation that will use the sensor or panoramic unit
• Run a test capture to make sure the software properly recognizes the device
If you purchased your equipment through Global Imaging USA, our team can walk you through this over the phone or through a remote desktop session. We will make sure everything is configured correctly before moving on to the PMS integration.
Step 3: Set Up the TWAIN or Bridge Connection
This is where the two systems begin communicating.
Your PMS and imaging software typically connect using one of the following methods:
TWAIN
Technology Without An Interesting Name. This industry standard protocol allows your PMS to launch imaging software directly from the patient chart.
Proprietary Bridge Software
Some imaging manufacturers provide dedicated bridge plugins designed specifically for certain PMS platforms.
DICOM Integration
For advanced imaging systems such as CBCT units, DICOM allows standardized image transfer between systems.
In most cases, you will open your PMS settings, navigate to the imaging integration section, and select your imaging software from a dropdown menu or browse to its executable file.
Once connected, clicking the X-ray button inside a patient chart should launch the capture software automatically.
Step 4: Configure the Image Storage Path
Your PMS needs to know where images are stored. This step is critical and often overlooked.
Improper storage paths are a common cause of missing image errors.
Best practices
• Use a shared network folder if your office has multiple workstations
• Ensure all machines point to the same image directory
• Confirm the folder has proper read and write permissions
• Match the folder path inside both your imaging software and PMS settings
Pro Tip
Use a naming convention based on patient ID instead of patient name. This prevents duplicate folders and simplifies future software migrations.
Step 5: Test with a Real Patient Chart
Do not wait until a patient is sitting in the chair to test your system.
Open a test chart inside your PMS and walk through the entire workflow.
Test the full process
• Select the patient chart
• Click the imaging or X ray button
• Capture a test image using a phantom or test object
• Confirm the image saves to the correct folder
• Verify the image appears in the patient chart
• Close the imaging software and reopen to confirm the image remains
If anything fails during this process, troubleshoot now instead of discovering the issue during a busy morning schedule.
Step 6: Train Your Team
Even the best integration can fall apart if the team is unsure how to use it.
Schedule a short 15 to 30-minute training session that covers:
• Launching imaging from inside the PMS
• Locating and retrieving stored images
• Basic troubleshooting steps
• Who to contact for support
Write down the essential steps and keep them posted near each workstation. This simple step can significantly reduce support calls during the first few weeks.
Step 7: Set Up a Backup Strategy
Dental images are clinical records. They are legally required and irreplaceable.
Once your integration is running smoothly, confirm that your backup system includes image files in addition to the PMS database.
Backup options
• Cloud backup services
• Local NAS
• Hybrid solutions combining local and cloud backups
Many PMS platforms include built-in backup tools that can be configured to include your imaging directory.
Common Integration Issues and Quick Fixes
The PMS does not detect the imaging software
Make sure the imaging software is installed on the same workstation. Confirm that the correct TWAIN source is selected inside the PMS imaging settings.
Windows 11 Compatibility
Some imaging software or TWAIN drivers designed for older operating systems may experience compatibility issues on Windows 11. Ensure the latest version of the imaging software and sensor drivers are installed. Running the installation with administrator privileges and restarting the workstation can help ensure the device and software register correctly.
Images capture but do not appear in the patient chart
Verify the storage path is identical in both programs. Also check folder permissions.
The sensor works on one computer but not another
Drivers and imaging software must be installed on every workstation that will use the device. USB sensors also need to be physically connected to that machine.
TWAIN errors appear
Close all imaging-related software. Disconnect the sensor, reconnect it, and relaunch the programs. If the issue continues, reinstall the TWAIN driver.
